Transpartent PVC Coated Overlay Film For Plastic Cards Lamination
PVC coated overlay film is the ultimate solution for improving the durability and appearance of plastic cards. Designed to protect and personalize a variety of plastic cards, this high-quality film offers superior scratch resistance, fading protection, and enhanced durability, making it ideal for use in ID cards, membership cards, loyalty cards, access control cards, and other personalized card applications.
PVC coated overlay film is engineered to be compatible with thermal transfer and hot stamping technologies, allowing for easy integration into card production processes. It ensures that your cards not only look great but also stand the test of time, resisting wear and environmental damage.
It has higher peel strength and it is suitable for laminating with most of PVC sheets printed by various printers.
One side is a smooth surface, another side is coved with glue.
PVC coated overlay film are commonly used in the production of identification cards, such as driver's licenses, ID cards, and access cards. These overlays consist of a thin layer of polyvinyl chloride (PVC) material that is applied on top of the printed card surface. The overlay serves as a protective coating, enhancing the durability and longevity of the card.
Features:
• Easy for magnetic stripe tape laying.
• Environmentally friendly, less emission to the atmosphere
• Suitable for hot press lamination machine type.
• Provide high bonding strength and give finished cards a glossy surface.
• Size is customized Card Film PVC Coated Overlay.
• Simplify card production process.
• Anti-abrasion, extend the life of cards.
• Suitable for conventional ink and UV ink.
Applications:
• Government-issued cards and driver’s licenses
• Contactless RFID cards
• Financial and healthcare cards
• Custom-designed gift or loyalty cards
• Identity cards and smart cards
|
Serial
|
Item
|
|
Unit
|
Standard
|
|
number
|
PVC Coated Overlay Film
|
|
|
|
|
|
|
|
|
|
|
1
|
Width
|
|
mm
|
As client’s requirements
|
|
|
|
|
|
|
|
2
|
Length
|
|
mm
|
As client’s requirements
|
|
|
|
|
|
|
|
3
|
Thickness
|
|
mm
|
0.05-0.2mm
|
|
|
|
|
|
|
|
|
4
|
Tensile Strength
|
MD
|
|
MPa
|
≥40
|
|
|
|
|
|
|
|
|
5
|
Tensile Strength
|
CD
|
|
MPa
|
≥35
|
|
|
|
|
|
|
|
|
6
|
Heat Shrinkage MD
|
|
%
|
≥ -45(140℃+-2
|
|
|
|
|
|
℃/10min)
|
|
|
|
|
|
|
|
|
7
|
Heat Shrinkage CD
|
|
%
|
≤ 30(140℃+-2
|
|
|
|
|
|
℃/10min)
|
|
|
|
|
|
|
|
|
8
|
Density
|
|
g/cm3
|
1.26+-0.04
|
|
|
|
|
|
|
|
9
|
Vicat Softening Point
|
|
℃
|
74+-5(5KG)
|
|
|
|
|
|
|
|
10
|
Peel Strength
|
|
N
|
≥4
|
|
|
|
|
|
|
FAQ
Q1. Can I have a sample order ?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: 1-5 days for Sample preparing ,10-15 working days for mass production.
Q3. Do you have any MOQ limit ?
A: Sample is available, Order MOQ is 200KGS.
Q4. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order ?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6: Do you offer guarantee for the products?
A: Yes, we offer 5 years warranty to our products.
Q7: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.1%.
Secondly, during the guarantee period, we will send the new goods with good quality for the faulth. We can discuss the best solution together.
